Safety Controlstick
Next-generation joystick for agricultural machinery
The new joystick SAFETY CONTROLSTICK represents the next generation of intelligent control devices designed for future cabin platforms.
Developed to be universal, robust, and ergonomic, it combines a refined design with advanced electronics fully compatible with the CAN J1939 protocol.
Adjustable and customizable LED backlighting, immediate visual feedback, and a reinforced mechanical structure with an internal metal frame ensure reliability and comfort even in the most demanding environments.
Thanks to its modular architecture and configurable connectivity, the joystick can be integrated into both self-propelled and trailed machines, offering precise and safe operation.
Certified according to ISO 25119 (AgPL C) and compliant with EMC and CE regulations, this new-generation joystick is ready to support the agricultural machinery of tomorrow with technology, safety, and style.
CHARACTERISTICS
- Supply voltage: 9–32 V DC
- Communication: CAN 2.0B – SAE J1939 / CAN-FD support
- Bus speed: 250 / 500 / 1000 kbit/s
- Backlighting: LED green/white, adjustable intensity (0–100%)
- Buttons: Up to 35 buttons with monitored CAN status
- Keypad: Oil- and wear-resistant silicone
- Structure: Integrated metal frame, reinforced design
- Protection: IP65
- Operating temperature: –30 °C ÷ +85 °C (–40 °C for 24 h)
- Connector: Deutsch DT04-4P
- Functional safety: AgPL C – ISO 25119, MTTFd ≥ 220 years
