Home / Products / Displays / 10VIEW
INVEHICLE
Back to products
D52

10VIEW

10VIEW is a high-performance 10” display, ideal for tractors, construction machinery and all off-highway vehicle. With its unique optical performance and resistance to harsh environments, it can be installed either flush or surface mounted.

Category: Displays
Share:
  • Description
Description

TECHNICAL FEATURES

  • Operating voltage: 6 – 32 Vdc, protected against reverse polarity
  • Operating temperature: -30°C +85°C
  • Sealing: IP67
  • CPU: Arm® Cortex®-A9
  • RAM: 5MB
  • FLASH: 32MB
  • HW Watchdog
  • DISPLAY: COLOR TFT 10,1” 1024X600 1000NITS IPS TECHNOLOGY
  • CAPACITIVE TOUCHSCREEN
  • 5 LED indicator or 5 silicon pushbutton
  • 1 buzzer 105dB @30cm
  • 1 internal RTC (real time clock)
  • Programmable in C languages with API or with eDASH3K
  • CAN bootloader for FW upgrade
  • 3 CANBUS ports
  • 1 USB port
  • 1 LINBUS port
  • 1 UART TTL (for debug)
  • 22 DIGITAL INPUT(analogici)
  • 8 RESISTIVE (2 INPUT for PT100/1000)…
  • 4 frequency INPUT (0-10KHz,  PICKUP, PNP, NPN)
  • 2 IN 4-20mA
  • 2 IN 0-10V
  • 4 HSD OUTPUT 1A
  • 1 Vout for external senso (5V o 10V) (+ e GND)
  • 2 video INPUT

DOWNLOAD

Tecnical Brochure
3D Model Panel
3D Model Ram
